Welcome to the Future: Pure Wi-Fi 7 with BE11000 Speed
The Cudy M11000 is your ticket to the fast lane on the data highway. With the revolutionary Wi-Fi 7 standard, you'll achieve speeds that were previously unimaginable. Thanks to technologies like Multi-Link Operation (MLO), which uses multiple frequency bands simultaneously, and the double channel width of 320 MHz in the 6 GHz band, latency spikes and connection drops are a thing of the past. Whether you're streaming in 8K, diving into virtual reality, or aiming for victory in online gaming – this mesh Wi-Fi system provides the stable and ultra-fast foundation you need.
No Compromises: Full 2.5-Gigabit Power on Every Port
What good is the fastest Wi-Fi if your wired connections are a bottleneck? Cudy thought ahead and equipped the M11000 with four 2.5-Gigabit Ethernet ports. This means you get the performance of a high-speed Ethernet Switch built right in, perfect for all your wired devices and Cabling. Connect your high-end gaming PC, NAS system, or workstation and benefit from maximum wired speed. It's also ideal for the wired backhaul between two mesh nodes to guarantee an absolutely rock-solid and lightning-fast connection throughout your home.
Stable Network for Everyone: Power CPU for up to 200 Devices
In a modern smart home, dozens of devices quickly add up. The Cudy M11000 is perfectly prepared for this. At the heart of the system beats a powerful 1.5 GHz quad-core processor, supported by 512 MB of DDR4 RAM. This hardware foundation ensures that your Network remains stable and responsive even with intensive use by many smartphones, laptops, smart TVs, and IoT devices. Effortlessly manage up to 200 clients without any performance degradation.
Your Secure Fortress: Comprehensive VPN Functions for Your Home Network
Security and privacy are more important than ever. The Cudy M11000 is more than just a fast router; it's also a flexible VPN hub. With native support for modern and fast protocols like WireGuard and OpenVPN, you can set up the system as both a VPN server for secure access to your home network on the go and as a VPN client to protect all your data traffic through an external provider. Maximum control and security for your digital activities.
Strengths & Notes at a Glance
- Pro: Future-proof Wi-Fi 7 technology with extreme speeds and the lowest latencies.
- Pro: Full 2.5-Gigabit connectivity on all four Ethernet ports eliminates network bottlenecks.
- Pro: Powerful quad-core CPU ensures high stability, even with up to 200 connected devices.
- Pro: Comprehensive and modern VPN support (WireGuard, OpenVPN) as both server and client.
- Note: To unleash the full potential of Wi-Fi 7, you need compatible end devices (smartphones, laptops, etc.).
- Note: The system is a pure router and requires a separate modem from your internet Service provider.
Specifications & Features
| Manufacturer: | Cudy |
| Model: | M11000 (1-Pack) |
| EAN: | 6971690793616 |
| HAN/MPN: | M11000 |
| Product Classification: | Mesh Wi-Fi System, Router |
| Processor (CPU): | Qualcomm Quad-Core, 1.5 GHz |
| Memory (RAM): | 512 MB DDR4 |
| Flash Memory: | 128 MB NAND |
| Max. Connected Devices: | Up to 200 |
| Wi-Fi Standard: | Wi-Fi 7 (IEEE 802.11be) |
| Backward Compatibility: | 802.11a/b/g/n/ac/ax |
| Frequency Bands: | Tri-Band (2.4 GHz, 5 GHz, 6 GHz) |
| Maximum Wi-Fi Speed: | BE11000 (approx. 11,000 Mbps) |
| Speed 6 GHz: | Up to 5765 Mbps |
| Speed 5 GHz: | Up to 4324 Mbps |
| Speed 2.4 GHz: | Up to 688 Mbps |
| Antennas: | 6x internal high-performance Antennas |
| Wi-Fi Streams: | 6-Stream (2x2 + 2x2 + 2x2) |
| Wi-Fi 7 Technologies: | Multi-Link Operation (MLO), Preamble Puncturing |
| Other Wi-Fi Technologies: | 4K-QAM, 320 MHz Channel Width, MU-MIMO, OFDMA, Beamforming, BSS Coloring |
| Wi-Fi Coverage (per unit): | Up to 250 m² (under ideal conditions) |
| Ethernet Ports: | 4x 2.5-Gigabit Ethernet Ports |
| WAN/LAN Configuration: | 1x 2.5G WAN + 3x 2.5G LAN (flexibly assignable) |
| USB Port: | 1x USB 3.2 Gen 1 (USB 3.0) |
| Buttons: | WPS, Reset |
| Status Indicator: | LED Indicator |
| Operating Modes: | Router, Access Point, Mesh System |
| Security: | WPA/WPA2/WPA3, SPI Firewall, DoS Protection, MAC/IP Filter |
| VPN Server: | OpenVPN, WireGuard, IPsec, Zerotier, PPTP, L2TP |
| VPN Client: | OpenVPN, WireGuard, IPsec, Zerotier, PPTP, L2TP |
| Management: | Web Interface, Cudy App (iOS/Android) with Cloud Access |
| Additional Features: | QoS, Guest Network, Parental Controls, VLAN, DDNS, Port Forwarding, UPnP |
| Power Supply: | External Power Adapter (12V / 2A) |
| Power Consumption: | approx. 12 W (idle), max. 22 W |
| Dimensions (H x W x D): | 202 x 116 x 116 mm |
| Weight (per unit): | approx. 852.5 g |
What's in the Box
| 1 x Cudy M11000 Unit |
| 1 x Power Adapter |
| 1 x RJ45 Ethernet Cable |
| 1 x Installation Guide |
Frequently Asked Questions (FAQ)
Can you use all four ports as LAN ports for your wired devices?
Yes, absolutely! When you use an M11000 unit as your main router, one port becomes the WAN port for your modem. The other three ports are then available as ultra-fast 2.5G LAN ports for your network. If you add another unit as a mesh node, you can even use all four of its ports as LAN ports for your wired devices.
Does your Cudy M11000 support wireless and wired backhaul simultaneously?
Yes, the Cudy mesh system is super flexible. You can connect the mesh nodes purely wirelessly to avoid extra Cabling. For maximum stability and speed, you can also connect them via Ethernet Cables (wired backhaul). The system always intelligently chooses the best path for data transmission in your network.
Do you need special settings to use the 6 GHz band?
No, the 6 GHz band is activated automatically. You just need to make sure your end devices, like your smartphone or laptop, support Wi-Fi 6E or Wi-Fi 7. Only these new standards can access the exclusive 6 GHz band. Your older devices will simply connect automatically to the 5 GHz or 2.4 GHz band, ensuring compatibility across your whole network.
How complicated is it to set up a mesh network with a second unit?
It's incredibly easy and user-friendly! You configure the first unit conveniently via the Cudy app or the web interface. To add a second unit, you just switch it on and add it to your existing mesh network in a few simple steps, either by pressing a button or through the app.
Can you use the USB 3.0 port for an external hard drive as network-attached storage (NAS)?
Yes, of course! The USB 3.0 port is perfect for that. Just connect an external hard drive or a USB stick, and you can access your files from any device in your home network using protocols like Samba (SMB) or FTP.
Can I expand my Cudy mesh system with devices from other manufacturers?
No, the Cudy mesh system uses special technology to guarantee an optimal and seamless connection between the individual M11000 units. To build or expand your mesh network, you must exclusively use Cudy mesh-compatible WiFi Routers and devices.
