The AVM Fritz!Box 7510 is a powerful WiFi router with an integrated DSL modem designed to meet the demands of modern home networks. With its support for DSL technology, it enables fast and reliable internet connections over DSL connections. The Fritz!Box 7510 offers a variety of features that make it an ideal choice for use in households and small offices. The Fritz!Box 7510 utilizes the current WiFi standard, WiFi 6, thus achieving data rates of up to 600 Mbps. Additionally, it has a Gigabit Ethernet port for fast wired connections and supports DSL connections of up to 300 Mbps.
Gigabit Ethernet
The Fritz!Box 7510 offers a variety of features and options for various applications. It has a Gigabit Ethernet port for wired connections and WiFi with support for the WiFi 6 standard (802.11ax) for wireless connections. This allows users to benefit from fast and stable internet connections that also support demanding applications such as 4K video streaming or online gaming.
WLAN
The Fritz!Box 7510 supports the latest WiFi 6 standard but is also backward compatible with WiFi 802.11g and n. Additionally, it supports WiFi mesh networks, for example in combination with Fritz! Mesh repeaters.
DSL
The Fritz!Box 7510 supports DSL and VDSL connections up to 300 Mbit (including supervectoring). It is compatible with the Annex-J connections of Deutsche Telekom and supports VDSL Long Reach.
Telephony
The Fritz!Box 7510 is simultaneously a telephone system for IP-based connections and supports HD telephony for a natural sound. It has an integrated DECT base for up to 6 cordless phones.
Technical Specifications:
| Manufacturer / Model: |
AVM / Fritz!Box 7510 ax |
| Processor: |
Maple @ 1000 MHz - ARM Cortex A53 |
| Memory: |
512MB RAM |
| WiFi Frequency Band: |
2.4GHz |
| WiFi Transmission Rates: |
600Mbps |
| WiFi: |
WiFi ax (WiFi 6) up to 600 Mbit/s gross (2.4 GHz) |
| Telephony: |
Telephone system for IP-based connections, Integrated DECT base for up to 6 cordless phones, 1 a/b port (optional TAE or RJ11) for analogue telephone, answering machine or fax, Encrypted voice transmission ex factory, HD telephony for a natural sound, 5 integrated answering machines including email forwarding (voice to mail) |
| Security: |
WPA2 encryption, additional WPA3/2 transition mode available |
| Interfaces: |
1 x VDSL or ADSL connection, 1 x Gigabit LAN, 1 x USB 3.0 port for storage and printer, 1 a/b port (optional TAE/RJ11) for analogue telephone, answering machine or fax |
| LAN Interface: |
1 x 10/100/1000MBit LAN Ports |
| Power Consumption: |
Average power consumption: 6 Watts |
| Application Area: |
Indoor |
| E-Label: |
Yes |
| Dimensions: |
208 x 150 x 37 mm |
| Weight: |
0.574 kg |
Scope of Delivery:
| 1 x AVM FRITZ!BOX 7510 ax |
| Power Supply Unit |
| 4 m Long DSL Connection Cable |
| 1.5 m Long LAN Cable |
| Quick Guide |
