No more cable clutter: Your Network gets smart!
You surely know this: Your Network is growing, more and more devices need not only a data connection but also a power supply. This quickly leads to messy cable clutter, additional power strips, and increased installation effort. Especially with IP Cameras, WiFi Access Points, or VoIP phones, separate power supply is often a challenge. The TP-Link TL-SG1016PE Gigabit Easy Smart PoE+ Switch is your answer to these challenges. With its 16 Gigabit RJ45 ports, 8 of which support PoE+, you can transmit data and power over a single Ethernet cable. This significantly simplifies installation, reduces Cabling effort, and creates a tidier and more efficient Network.
Smart Management Made Easy
Performance meets user-friendliness! This PoE+ Switch delivers a total PoE budget of 150 watts, with each of the 8 PoE+ ports providing up to 30 watts – ideal for power-hungry devices. Thanks to the Easy Smart Management functions, accessible via an intuitive web interface, you can easily configure Quality of Service (QoS) for prioritized data traffic, VLANs for network segmentation, or IGMP Snooping for optimized multicasting. This gives you full control over your network without getting lost in complex menus.
Robust, Quiet, and Future-Proof
The TP-Link TL-SG1016PE is not only powerful but also designed for durability. The robust metal housing protects the high-quality electronics and allows for both desktop use and mounting in 19-Inch Racks. And best of all: It is designed to be fanless, which guarantees extremely quiet operation. This makes it the perfect choice for office environments or other noise-sensitive areas. With this Ethernet Switch, you invest in a future-proof network that is not only powerful but also flexible and easy to manage.
Maximum Flexibility for Your Devices
Benefit from improved network efficiency, reduced operating costs, and the certainty that your devices are reliably supplied with data and power. Whether you want to upgrade your home network or set up a professional office environment – the TL-SG1016PE offers you the necessary flexibility. Experience how easy professional network management can be and enjoy the benefits of a tidy and powerful network.
Strengths & Notes at a Glance
- Pro: 8 PoE+ ports with 150 Watt total budget for flexible power supply.
- Pro: Gigabit speed on all 16 ports for fast data transfer.
- Pro: Easy Smart Management via Web GUI for simple configuration of QoS and VLANs.
- Pro: Fanless design for extremely quiet operation.
- Pro: Robust metal housing and rackmount kit for versatile installation.
- Note: Ideal for small to medium-sized networks that want to integrate PoE devices.
Specifications & Features
| Manufacturer: | TP-Link |
| Model: | TL-SG1016PE |
| Product Type: | Gigabit Easy Smart PoE+ Switch |
| Ports: | 16 x 10/100/1000 Mbps RJ45 (Auto-Negotiation, Auto-MDI/MDIX) |
| PoE Ports: | 8 x PoE+ (IEEE 802.3af/at) |
| Total PoE Budget: | 150 Watts |
| PoE Power per Port: | Up to 30 Watts |
| Switching Capacity: | 32 Gbps |
| Packet Forwarding Rate: | 23.8 Mpps |
| MAC Address Table: | 8K Entries |
| Jumbo Frame: | 9 KB |
| Management: | Web-based GUI (Easy Smart) |
| Advanced Features: | QoS, VLAN, IGMP Snooping, Link Aggregation, Port Mirroring, Loop Prevention, Auto PoE Recovery |
| Housing: | Metal, Desktop/Rack-mountable (19-inch) |
| Fan: | Fanless |
| Dimensions (W x D x H): | 294 x 180 x 44 mm |
| Power Supply: | Internal, 100-240 VAC, 50/60 Hz |
| Operating Temperature: | 0°C to 40°C |
| Certifications: | CE, FCC, RoHS |
| Standards: | IEEE 802.3, 802.3u, 802.3ab, 802.3x, 802.3af, 802.3at |
Scope of Delivery
| 1 x TP-Link TL-SG1016PE Gigabit Easy Smart PoE+ Switch |
| 1 x Power Cable |
| 1 x Rackmount Kit |
| 1 x Installation Guide |
Frequently Asked Questions (FAQ)
What is the TP-Link TL-SG1016PE and what is it used for?
The TP-Link TL-SG1016PE is a 16-port Gigabit Desktop Switch, 8 of which support PoE+. It is used to expand networks and provide power and data to PoE-enabled devices such as IP Cameras, WiFi Access Points, or VoIP phones.
How many PoE+ ports does the TL-SG1016PE have and what power do they provide?
The TL-SG1016PE has 8 PoE+ ports (802.3at/af compliant). Each of these ports can deliver up to 30W, with a total PoE budget of 110W for all PoE ports combined.
Is the TP-Link TL-SG1016PE a Managed or Unmanaged Switch?
The TP-Link TL-SG1016PE is an Unmanaged Switch. This means it is plug-and-play and requires no configuration, making it ideal for small and medium-sized offices or home networks.
What advantages does a Gigabit Switch like the TL-SG1016PE offer?
A Gigabit Switch offers data transfer rates of up to 1000 Mbps, which is ten times faster than Fast Ethernet. This enables fast transfer of large files and smooth use of bandwidth-intensive applications.
Can I also connect non-PoE devices to the PoE+ ports of the TL-SG1016PE?
Yes, the PoE+ ports of the TL-SG1016PE automatically detect whether a connected device requires PoE. If not, only the data connection is established without supplying power, which protects the devices.
Is the TL-SG1016PE suitable for desktop use or rack mounting?
The TL-SG1016PE is designed as a Desktop Switch, allowing for flexible placement on a desk or in small network cabinets.
