Your Connection, Triple-Secured: Dual-SIM, eSIM & WAN Failover
The RUTX50 is designed for maximum availability. With two physical SIM slots, an integrated eSIM, and a WAN port that can serve as a backup internet source, you're prepared for any Network outage. Configure the automatic failover so the router seamlessly switches to an alternative connection if the primary line weakens or a data limit is reached. This ensures your business-critical processes continue without interruption – an absolute necessity for payment terminals, IP Cameras, or industrial control systems.
Built for Extremes: The 5G Router for Control Cabinets and Vehicles
Where other WiFi Routers give up, the RUTX50 is just getting started. Its robust aluminum Enclosure and extreme operating temperature range of -40°C to 75°C make it ideal for use in the harshest conditions. Thanks to the wide input voltage range of 9 to 50 Volts DC, you can connect it directly to the 12V onboard system in a Teltonika RUTX50 for vehicle internet installation or to 24V industrial systems. The flexible Mounting Systems for DIN rails or flat surfaces make integration into any control cabinet a breeze.
Full Control with RutOS and Remote Management
The heart of the router is the powerful operating system (RutOS), based on OpenWrt. It offers you a wealth of configuration options that go far beyond standard routers. Set up complex VPN tunnels with WireGuard or OpenVPN, define granular firewall rules, and use professional Network features like VLANs or Load Balancing. In combination with the Teltonika Remote Management System (RMS), you can centrally manage an entire fleet of routers, roll out firmware updates, and change settings without ever having to be on-site – a crucial advantage for a 5G Router with eSIM for Remote Management.
More Than Just Internet: GPS Tracking and I/O Functions
The RUTX50 is not just a gateway to the internet, but also an intelligent IoT platform. The integrated GNSS receiver (GPS, GLONASS, etc.) enables precise location tracking for your vehicles or mobile assets. Set up geofencing zones and receive notifications when a device leaves or enters a defined area. Via the digital input and output on the power connector, you can also read external sensors or switch small actuators to implement simple automation tasks directly through the router.
Strengths & Notes at a Glance
- Pro: Extreme connectivity redundancy through Dual-SIM, eSIM, and WAN failover for maximum reliability.
- Pro: Future-proof with 5G (SA & NSA) and an excellent 4G (4G Cat 20) fallback for best performance.
- Pro: Industrial durability with a wide temperature range (-40°C to 75°C) and flexible Power Supply (9-50V DC).
- Pro: Powerful RutOS based on OpenWrt with in-depth configuration options (VPN, Firewall, etc.) and RMS compatibility.
- Note: The high complexity of RutOS can be overwhelming for beginners.
- Note: Equipped with Wi-Fi 5, not the newer Wi-Fi 6 standard, which could be relevant for environments with very high WiFi demand.
Specifications & Features
| Manufacturer: | Teltonika |
| Model: | RUTX50 (with eSIM) |
| EAN: | 4779051844524 |
| HAN/MPN: | RUTX50 |
| Device Classification: | Industrial 5G Cellular Router |
| Mobile | |
| 5G Technology: | Sub-6 GHz, SA (Standalone) & NSA (Non-Standalone) |
| 5G Download Speed: | Up to 3.3 Gbps (4x4 MIMO) |
| 5G Upload Speed: | Up to 900/600 Mbps (2x2 MIMO) |
| 4G Technology: | 4G Cat 20 |
| 4G Download Speed: | Up to 2.0 Gbps |
| 4G Upload Speed: | Up to 200 Mbps |
| 3G Technology: | WCDMA |
| 3G Download Speed: | Up to 42 Mbps |
| 3G Upload Speed: | Up to 5.76 Mbps |
| SIM Slots: | 2x Mini-SIM (2FF), 1.8V/3V |
| eSIM: | Yes, integrated eUICC |
| Mobile Features: | Dual-SIM with Auto-Failover, Backup-WAN, Band-Lock, Auto-APN |
| Mobile Antenna Connectors: | 4x SMA |
| WiFi | |
| WiFi Standard: | IEEE 802.11b/g/n/ac Wave 2 (Wi-Fi 5) |
| Frequency Bands: | Dual-Band (2.4 GHz & 5 GHz) |
| Data Rate: | Up to 867 Mbps |
| Security: | WPA3, WPA2, ESSID Stealth Mode |
| Operating Modes: | Access Point (AP), Station (STA) |
| WiFi Features: | MU-MIMO, Fast Roaming (802.11r), Wireless Mesh (802.11s) |
| Concurrent Clients: | Up to 150 |
| WiFi Antenna Connectors: | 2x RP-SMA |
| Ethernet | |
| Ports: | 5x Gigabit Ethernet (10/100/1000 Mbps) |
| Configuration: | 1x WAN (configurable as LAN), 4x LAN |
| Hardware & System | |
| CPU: | Quad-Core ARM Cortex A7, 717 MHz |
| RAM: | 256 MB |
| Flash Storage: | 256 MB |
| Operating System: | RutOS (based on OpenWrt) |
| USB Port: | 1x USB 2.0 Host |
| Location (GNSS) | |
| Systems: | GPS, GLONASS, BeiDou, Galileo, QZSS |
| GNSS Antenna Connector: | 1x SMA |
| GNSS Features: | NMEA 0183, Geofencing, TAVL/RMS Compatibility |
| Physical Properties | |
| Casing Material: | Aluminum |
| Dimensions (W x H x D): | 132 x 44.2 x 95.1 mm |
| Weight: | 533 g |
| Power Connector: | 4-pin industrial connector |
| Input Voltage: | 9 - 50 VDC |
| PoE (passive): | Yes, Mode B via LAN1 port |
| Operating Temperature: | -40°C to 75°C |
| Mounting: | DIN rail, surface mount |
| Inputs & Outputs (I/O) | |
| Digital Input: | 1x (on 4-pin power connector) |
| Digital Output: | 1x Open Collector (on 4-pin power connector) |
| Grounding: | 1x Grounding screw |
Package Contents
| 1 x Teltonika RUTX50 Router |
| 1 x 18W Power Supply |
| 4 x Mobile antenna (swivel, SMA male) |
| 2 x WiFi Antenna (swivel, RP-SMA male) |
| 1 x GNSS antenna (adhesive, SMA male, 3m cable) |
| 1 x Ethernet Cable (1.5m) |
| 1 x SIM adapter kit |
| 1 x Quick Start Guide |
Frequently Asked Questions (FAQ)
Can you use two SIM cards simultaneously for more speed with your Teltonika RUTX50 5G router?
No, you can't use both SIM cards at the same time for combined speed (bonding). The dual-SIM feature in these Teltonika LTE / 5G Routers is designed for redundancy. You can set up your device to automatically switch to the second SIM card (failover) if the first connection becomes weak, reaches a data limit, or the Network fails.
Which Antennas do you need for optimal 5G reception with your RUTX50?
For the best possible 5G reception, you should use one of the external 4x4 MIMO 5G Antennas / Outdoor Antennas and connect it to the four SMA ports labeled 'Mobile'. The included set is a good start, but for challenging locations, like inside metal Enclosures or in your Yacht / Camper / Motorhome, an externally mounted MIMO antenna like our Vehicle Antennas - LTE, 5G, WiFi is crucial.
What's the benefit of the eSIM in the Teltonika LTE / 5G Routers like the RUTX50?
The integrated eSIM is ideal for large or hard-to-reach installations, perfect for many M2M / IoT applications. You can ship the router without a physical SIM card and then remotely upload and activate the mobile profile later. This also allows you to switch providers without needing to be physically on-site, saving you time, costs, and the need for on-site Service.
Can you use the RUTX50 as a GPS Tracker for your vehicle or asset?
Yes, absolutely! The router has a built-in GNSS receiver that supports GPS, GLONASS, and other systems. With a connected GNSS antenna, you can pinpoint your device's exact location, set up geofencing zones, or send the position data to a server.
Can you connect the RUTX50 directly to your car's 12V battery?
Yes, that's no problem at all. The RUTX50 has a very wide input voltage range of 9 to 50 Volts DC, unlike devices that need specific PoE Injectors / Power Supplies. You can connect it directly to a 12V electrical system in a car or truck, or to a 24V system in industrial applications, without needing a separate voltage converter.
Is the WiFi from the RUTX50 WiFi Router strong enough for your whole house?
The WiFi is solid, but remember: the RUTX50 is a professional industrial router, not a mesh system designed to replace multiple WiFi Access Points or WiFi Repeaters at home. Its WiFi power is perfect for your vehicle, a container, or a small office. For a whole house with multiple floors, the signal might be too weak. Our tip: Use the RUTX50 as a super-strong 5G gateway and simply connect your own mesh WiFi system behind it for full home coverage.
