Your Upgrade for Stable 5G & 4G: The WMM8G-7-38-5SP
No more slow internet and connection drops. The Panorama WMM8G-7-38-5SP is your professional solution for first-class mobile reception. This directional Antenna was specially developed to specifically amplify your router's signal. With its enormous frequency bandwidth of 617-960 MHz and 1710-3800 MHz, it is not only a master for all common 4G networks, but also perfectly equipped for the 5G era. It is the ideal partner for modern 4G / 5G Routers and ensures a stable, fast connection where Others have long given up.
9 dBi Peak Gain: Solving Signal Problems Specifically
As a directional Antenna, the WMM8G-7-38-5SP bundles its entire reception power in one direction – directly towards the nearest cell tower. The result is an impressive peak gain of up to 9 dBi. Interference signals from other directions are effectively filtered out, which drastically improves signal quality (SINR). Thanks to the integrated 2x2 MIMO technology, two data streams are used simultaneously to maximize your connection's transmission speed and stability. Both cables must be connected to your router for this.
Built for Any Weather: Robust IP65 Construction
Whether rain, snow, or strong sunlight – this Antenna is made for permanent outdoor use. The housing is made of impact-resistant and UV-stable ASA plastic and is IP65 certified. This means it is completely dustproof and protected against jet water. With the included Antenna Mounting Accessories, you can flexibly position it on a wall, a mast, or even on a windowsill. It thus belongs to the absolute top class of 5G Antennas / Outdoor Antennas and is an investment in long-lasting performance.
Plug & Play: Easy Installation Without Compromises
Panorama has thought of everything to make installation as easy as possible for you. The antenna comes with two permanently connected, 5-meter long and double-shielded CS29 Low-Loss Coaxial Cables. These end in universal SMA connectors that fit most 4G/5G Routers. This eliminates the need to buy separate Antenna Cables or work with adapters, minimizing potential signal losses from the outset. Simply align, connect, and immediately enjoy better reception.
Strengths & Notes at a Glance
- Pro: Excellent frequency range covering all 4G and important 5G bands, making it extremely future-proof.
- Pro: High and stable gain of up to 9 dBi for significant signal improvement and stable data rates.
- Pro: Very robust, weatherproof (IP65), and UV-stable housing for long-lasting outdoor use.
- Pro: Comprehensive Antenna Mounting Accessories for wall, mast, and table installation offers maximum flexibility.
- Pro: Easy Plug & Play installation due to permanently integrated 5m cables with standard SMA connectors.
- Note: As a directional antenna, it must be precisely aligned with a cell tower for optimal performance.
- Note: The fixed cable length of 5 meters may require an extension for long distances to the router, leading to slight signal attenuation.
Specifications & Features
| Manufacturer: | Panorama Antennas Ltd. |
| Model: | WMM8G-7-38-5SP |
| EAN: | 5055416000477 |
| Predecessor Model: | WMM8G-7-27-5SP |
| Product Type: | External 2x2 MIMO Directional Antenna (Client Antenna) |
| Purpose: | Signal amplification for mobile networks |
| Frequency Bands: | 617-960 MHz, 1710-3800 MHz |
| Supported Networks: | 2G, 3G, 4G (4G), 5G (incl. bands n77/n78) |
| Peak Gain: | 9 dBi |
| Polarization: | Cross Polarised |
| Radiation Pattern: | Directional |
| Impedance: | 50 Ohm |
| Max. Input Power: | 50 Watt |
| VSWR: | < 2.5:1 |
| Number of Antenna Elements: | 2 (for 2x2 MIMO) |
| Connectors: | 2x SMA Male |
| Cable Type: | 2x permanently integrated, double-shielded CS29 Coaxial Cable (Low Loss) |
| Cable Length: | 2x 5 Meters |
| Housing Material: | UV-stable, impact-resistant ASA |
| Color: | White |
| IP Protection Class: | IP65 (dustproof, protected against jet water) |
| Operating Temperature: | -30°C to +80°C |
| Dimensions: | 230 x 180 x 94 mm |
| Weight: | 955 g |
| Mounting Options: | Wall mounting, mast mounting, table/windowsill stand |
Scope of Delivery
| 1 x Panorama WMM8G-7-38-5SP Antenna with 2x 5m Cables and SMA Connectors |
| 1 x Mounting material for wall, mast, and table mounting |
Frequently Asked Questions (FAQ)
Is the Panorama WMM8G-7-38-5SP suitable for 5G?
Yes, the antenna is suitable for 5G. It covers important frequency bands from 3400 to 3800 MHz (3.4-3.8 GHz) used for 5G, such as Band n77/n78. This makes it a great 5G Antenna / Outdoor Antenna.
Do I need to connect two cables to my router?
Yes, absolutely. The antenna utilizes 2x2 MIMO technology to increase data rate and stability for your Network. Both SMA connectors must be connected to the corresponding antenna ports of your 4G / 5G Routers to achieve full performance.
Can I use this antenna indoors?
Yes, the antenna can also be used indoors; a desk stand for the windowsill is included. However, for optimal performance, outdoor mounting with a clear line of sight to the transmission mast is recommended. This is a versatile 5G Antenna / Outdoor Antenna.
How do I find the best location and correct alignment?
Use apps like 'OpenSignal' or 'CellMapper' to find the direction of the strongest transmission mast. Mount the antenna as high as possible with a clear line of sight in that direction to maximize signal quality. Proper Antenna Mounting Accessories can help.
Is the antenna weather-resistant?
Yes, the antenna is certified with protection class IP65. This means it is completely dustproof and protected against jet water, making it ideal for permanent outdoor use as a robust 5G Antenna / Outdoor Antenna.
What is the difference from the previous model WMM8G-7-27?
The main upgrade of the WMM8G-7-38 model is the extension of the upper frequency range to 3800 MHz. This extension is crucial for compatibility with newer 5G frequency bands, enhancing its capability as a 5G Antenna.
